• Air conditioning, single-zone
• Assist handle, front passenger and driver on A-pillars
• Audio system feature, 4-speaker system
• Cruise control, steering wheel-mounted
• Door locks, power
• Floor covering, Graphite-colored rubberized-vinyl
• SiriusXM Satellite Radio, delete
• Steering column, manual Tilt-Wheel
• Steering wheel

• Air cleaner, high-capacity
• Alternator, 150 amps
• Battery, heavy-duty 720 cold-cranking amps/80 Amp-hr, maintenance-free with rundown protection and retained accessory power
• Differential, heavy-duty locking rear
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Four wheel drive
• Frame, fully-boxed, hydroformed front section
• Recovery hooks, front, frame-mounted, black
• Steering, Recirculating Ball
• Suspension Package, Standard includes 51mm twin tube shock absorbers and 33mm front stabilizer bar
• Transfer case, with floor-mounted shifter (Included with 4WD models only.)

• Air bag deactivation switch, frontal passenger-side
• Daytime Running Lamps with automatic exterior lamp control
• OnStar, delete also deletes driver information center compass.
• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist

Work Truck Preferred Equipment Group

• Standard Equipment

Additional Packages

• 2015 Interim Processing Code
• Alternator
• 220 Amps
• Black
• Defogger
• Rear-Window Electric
• License Plate Kit
• Front
• Mirror
• Inside Rearview Auto-Dimming
• Paint
• Solid (Std)
• Provision For Cab Roof-Mounted Lamp/Beacon Provides An Instrument Panel-Mounted Switch And Electrical Wiring Tucked Beneath The Headliner For A Body Upfitter To Connect A Body-Mounted Warning Or Emergency Lamp
• Rear Axle
• 4.10 Ratio
• Tires
• Lt235/80R17e All-Terrain
• Trailer Brake Controller
• Integrated

• UNDERBODY SHIELD frame-mounted shields includes front underbody shield starting behind front bumper and running to first cross-member protecting front underbody oil pan differential case and transfer case
• WORK TRUCK PREFERRED EQUIPMENT GROUP includes Standard Equipment
• SNOW PLOW PREP PACKAGE includes power feed for backup and roof emergency light (KW5) 220-amp alternator with gas or diesel engine forward lamp wiring harness (TRW) provision for cab roof mounted lamp/beacon (NZZ) underbody shield and Heavy Duty front-springs
• WT CONVENIENCE PACKAGE includes (DPN) outside heated power-adjustable vertical camper mirrors (DD8) inside rearview auto-dimming mirror and (AQQ) Remote Keyless Entry (Includes (A31) power windows.)
• REAR AXLE 4.10 RATIO
• CHEVROLET MYLINK AUDIO SYSTEM 4.2" DIAGONAL COLOR SCREEN WITH AM/FM STEREO USB ports auxiliary jack SD card slot Bluetooth® streaming audio for music and most phones hands-free smartphone integration Pandora Internet radio and voice-activated technology for radio and phone
• 2015 INTERIM PROCESSING CODE
• PAINT SOLID (STD)
• SEATS FRONT 40/20/40 SPLIT-BENCH 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. (STD)
• TIRES LT235/80R17E ALL-TERRAIN
• ALTERNATOR 220 AMPS
• BLACK
• TRAILER BRAKE CONTROLLER INTEGRATED
• WINDOWS POWER with driver express up and down and express down on all other windows
• DEFOGGER REAR-WINDOW ELECTRIC
• TRANSMISSION 6-SPEED AUTOMATIC HEAVY-DUTY electronically controlled with overdrive and tow/haul mode. Includes Cruise Grade Braking and Powertrain Grade Braking (STD)
• MIRROR INSIDE REARVIEW AUTO-DIMMING
• REMOTE KEYLESS ENTRY
• MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL CAMPER UPPER GLASS MANUAL-FOLDING AND EXTENDING BLACK. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp includes (DD8) auto-dimming inside rearview mirror.)
• DARK ASH CLOTH includes manually adjustable driver lumbar and Jet Black interior accents
• LICENSE PLATE KIT FRONT
• PROVISION FOR CAB ROOF-MOUNTED LAMP/BEACON provides an instrument panel-mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
• ENGINE VORTEC 6.0L VARIABLE VALVE TIMING V8 SFI (322 hp [240.1 kW] @ 4400 rpm 380 lb-ft of torque [513.0 N-m] @ 4200 rpm) (STD)
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hooks
• Steel Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Wheel Covers
• AM/FM Stereo
• MP3 Capability
• Bluetooth® Connection
• Auxiliary Audio Input
• Smart Device Integration
• Split Bench Seat
• Adjustable Steering Wheel
• Power Door Locks
• Cruise Control
• A/C
• ABS
• Dual Rear Wheels
• Traction Control
• Stability Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14.0 x 1.6
• Rear Brake Rotor Diam x Thickness (in): 14.0 x 1.6
• Cooling System
• Total Cooling System Capacity (qts): 16.4
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 220
• Emissions
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Cab to Axle (in): 59.06
• Front Bumper to Back of Cab (in): 117.10
• Height, Overall (in): 76.54
• Length, Overall w/o rear bumper (in): 229.5
• Overhang, Front (in): 38.8
• Wheelbase (in): 137.5
• Width, Max w/o mirrors (in): 80.12
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Aux Fuel Tank Capacity, Approx (gal): 40.0
• Aux Fuel Tank Location: Rear
• Fuel Tank Capacity, Approx (gal): 23.5
• Fuel Tank Location: Front
• Interior Dimensions
• Front Head Room (in): 42.8
• Front Hip Room (in): 60.75
• Front Leg Room (in): 45.28
• Front Shoulder Room (in): 66.02
• Passenger Capacity: 3
• Steering
• Steering Ratio (:1), On Center: 16.0
• Steering Type: Pwr
• Turning Diameter - Curb to Curb (ft): 46.9
• Summary
• Body Code: ZW9
• Body Style: Reg Cab 137.5" Wheelbase
• Vehicle Name: Chevrolet Silverado 3500HD Built After Aug 14
• Suspension
• Axle Capacity - Front (lbs): 5600
• Axle Capacity - Rear (lbs): 9750
• Axle Ratio (:1) - Front: 4.10
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 51
• Shock Absorber Diameter - Rear (mm): 51
• Spring Capacity - Front (lbs): 5600
• Spring Capacity - Rear (lbs): 9750
• Stabilizer Bar Diameter - Front (in): 1.31
• Suspension Type - Front: Independent
• Suspension Type - Rear: 3-Stage Spring
• Tires
• Front Tire Capacity (lbs): 2515
• Front Tire Order Code: QZT
• Front Tire Size: LT235/80R17E
• Rear Tire Order Code: QZT
• Rear Tire Size: LT235/80R17E
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Weight Information
• Curb Weight - Front (lbs): 5600
• Curb Weight - Rear (lbs): 5600
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Rear (lbs): 9750
• Gross Combined Wt Rating (lbs): 25000
• Gross Vehicle Weight Rating Cap (lbs): 13200
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 17 x 6.5
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 17 x 6.5
